首頁 >> 燃燒器配件 > 控制器 > 霍尼韋爾控制器(HONEYWELL) >

霍尼韋爾TF836

優惠活動： 8 折 免費咨詢：400 6789 872

為什么選擇旭禾熱工

  • 1

    電話購買

  • 2

    貨到付款

  • 3

    正規代理

  • 4

    保證原裝

  • 5

    電話購買

霍尼韋爾TF836產品介紹

產品介紹 -- 霍尼韋爾TF836

TF834.3/836.3 - Oil Burner Safety Control For 1- or 2-stage oil power burners up to 30kg/h capacity with or without oil preheater and intermittent operations. Flame detection: - Photoresistor MZ 770 S - Infrared-flicker detector IRD 1010 - UV solid state sensor UVD 970 A special contact in the control unit short-circuits the thermo-switch of the oil preheater as soon as the burner is operating and the flame signal is present. Therefore interruption of the burner due to decreasing oil temperature (e.g. in case of high oil flow) can be prevented. If the control box goes into lock-out mode, the oil preheater power supply is also disconnected.

型號表 -- 霍尼韋爾TF836

TF834.2 1-stage operation
post-ignition time ca. 20 sec.
low voltage protection according to EN230
TF834 E.3 1-stage operation
no post-ignition
low voltage protection according to EN230
TF836.3 2-stage operation
post-ignition time 2-4 sec.
low voltage protection according to EN230




技術參數 -- 霍尼韋爾TF836

暫無

參數說明 -- 霍尼韋爾TF836

暫無
